Sample Gauge
C/C = Change Course
L.O.A. = Length Overall (Ridge - Centre Gutter)
All dimensions are in millimetres to top of batten
|
Sample Roof |
Specimen |
L.O.A. 6720 |
Slate |
Gauge |
Courses |
Cumulative |
K |
65 |
1 |
6725 |
C/C K |
55 |
1 |
6660 |
J |
75 |
3 |
6605 |
C/C J |
60 |
1 |
6530 |
H |
90 |
6 |
6470 |
C/C H |
75 |
1 |
5930 |
G |
100 |
6 |
5855 |
C/C G |
90 |
1 |
5255 |
F |
110 |
6 |
5170 |
C/C F |
105 |
1 |
4510 |
E |
115 |
6 |
4405 |
C/C E |
95 |
1 |
3715 |
D |
125 |
5 |
3620 |
C/C D |
110 |
1 |
2995 |
C |
135 |
5 |
2885 |
C/C C |
120 |
1 |
2210 |
B |
150 |
3 |
2090 |
C/C B |
135 |
1 |
1640 |
A |
165 |
2 |
1505 |
C/C A |
140 |
1 |
1175 |
Q |
180 |
1 |
1065 |
C/C Q |
175 |
1 |
870 |
S |
200 |
1 |
700 |
C/C S |
150 |
1 |
500 |
| |
355 |
1 |
355 |
|
Centre Gutter |
0 |
|
|
